User manual of EC160 elevator intelligent integrated machine Function parameters
111
A1 floor setting
A2 floor displaying
H0 logic of the IO
control board
H1 logic of the car
control board
H2 front door stopping
floor
H3 rear door stopping
floor
H4 front/ rear door
stopping floor
L0 parallel and group
control setting
Logic setting 1 is the logic setting of below signal points:
Terminal C8 C7 C6 C5 C4 C3 C2 C1
Definition
Safety
edge
Closing
input
signal
Opening
input
signal
Door
closed
Door
open
OL DD Attendant
NO/NC ● ○ ○ ● ● ○ ○ ○
Binary 1 0 0 1 1 0 0 0
Decimal 1×128 0×64 0×32 1×16 1×8 0×4 0×2 0×1
H1_00
Logic
setting 1
128+16+8=152
Input point 1 to 8 (from low bit to high bit) are shown in binary numbers. The corresponding bit of
NO points set to be 0 and the NC to be 1. Write the convertering decimal result to logic 1.
The parameter is set to 004 if the OL switch is NC.
The parameter is set to (16+8)=24 if the Door closed/open is NC.
The parameter is set to 128 if the front door beam is NC.
The parameter is set to (8+16+128)=152, if the OL, door closed/open and beam are NC and others
are NO.
