User manual of EC160 elevator intelligent integrated machine Complete product description
179
9.4.4.5 Working environment
Temperature 0°~70°
Humidity <95%
Salt fog 0.13ug/m3
Shock Peak acceleration speed 100gn, 100 times
Vibration 10Hz-100Hz 50 times 100Hz-10Hz 50 times
Sudden pulse group interference 2.5kV
9.4.5 Definition of the input/output interface
9.4.5.1 Definition of power supply interface
P2 is the interface for working power supply of MC-GCL supplied by external DC24V switch power.
Serial
No.
Pin I/O Definition Remarks
P2
24- Input DC0V input terminal
24+ Input DC24V+input terminal
OUT- Output
DC0V power supply interface
for outside
OUT+ Output
DC24V+ power supply
interface for outside
9.4.5.2 Definition of CAN communication interface
CAN1 and CAN2 are CAN communication interfaces and the communication cable must be
twisted pairs.
Serial
No.
Pin I/O Definition Remarks
CAN1
CH1 Output
Communicate with EC160 H
terminal
Twisted pairs for
external connection
CL1 Output
Communicate with EC160 L
terminal
CG1 Output Grounding terminal of CAN1
Not grounded
generally
NC Output Not connected
CAN2
CH2 Output
Communicate with MC-GCL H
terminal
Twisted pairs for
external connection
CL2 Output
Communicate with MC-GCL L
terminal
