INVT EC160 User Manual

User manual of EC160 elevator intelligent integrated machine Function parameters
78
6.5.1 Parameters setting---master drive control
【main menu】
A system control
B fault record
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management
H system information
【parameters setting
inquiry】
P0 master drive
control
P1 speed and
deceleration distance
P2 motor parameters
P3 encoder
parameters
P4 running
comfortability
P5 elevator protection
parameters
P6 communication
setting
P7 drive information
PE factory only
【P0 master drive
control】
00 speed control mode
01 rated speed of the
elevator
02 Max. speed of the
elevator
03 Max. output
frequency
04 diameter of the
traction sheave
05 reduction ratio
06 suspension ratio of
the traction rope
07 carrier frequency
setting
08 running direction
selection
Function
code
Instruction Setting range【default value】 Remarks
P0_00 Speed control mode 0-2【1】
Not modify
in running
Select the speed control mode of the system.
0: VC without PG, only suitable on the debugging mode of the asynchronous master
1: VC with PG, encoder is needed
2: V/F control, only suitable on the debugging mode of the asynchronous master
Function
code
Instruction Setting range【default value】 Remarks
P0_01 Rated speed of the elevator 0.100~6.000m/s【1.750】
Not modify
in running
Input this parameter according to the name plate of the elevator. This is the basic value of the
actual speed of the elevator. Redo hoistway autotuning after modification.
