User manual of EC160 elevator intelligent integrated machine Installation and wiring
25
PE,
Grounding terminal
4.2.3 Specification of the main circuit leads
Model Input leads (mm²) Output leads (mm²)
Grounding
leads (mm²)
EC160-1R5-S2 2.5 2.5 2.5
EC160-2R2-S2 4 4 4
EC160-004-2 4 4 4
EC160-5R5-2 6 6 4
EC160-7R5-2 10 10 10
EC160-011-2 16 16 16
EC160-015-2 25 25 16
EC160-018-2 25 25 16
EC160-004-4 4 4 4
EC160-5R5-4 4 4 4
EC160-7R5-4 4 4 4
EC160-011-4 6 6 4
EC160-015-4 10 10 10
EC160-018-4 16 16 16
EC160-022-4 16 16 16
EC160-030-4 25 25 16
EC160-037-4 25 25 16
EC160-045-4 35 35 16
EC160-055-4 50 50 25
4.2.4 Configuration precautions
 The figures in the user manual are only examples and may be different
from the products you ordered.
 Connect according to the terminal grade. Shorten the length as short as
possible to avoid current leakage.
 Apply standard 3-phase 5-wire power supply. Ground the grounding
terminals with proper techniques. It is recommended to use multiple
twisted copper wires above 4mm² and ensure the grounding resistor is
