The single logic setting of I/O board is the logic setting of each point on I/O board. It can be
modified associated with logic setting 1-6:
【H0 IO I/O control
board logic setting】
00 logic setting 1
01 logic setting 2
02 logic setting 3
03 logic setting 4
04 logic setting 5
05 logic setting 6
06 logic setting of I/O
control board
07 reserved
08 reserved
【input signal 1-32】
1 low speed down
forced speed changing
2 low speed down
forced speed changing
3 low speed down
forced speed changing
4 low speed down
forced speed changing
5 low speed down
forced speed changing
6 low speed down
forced speed changing
7 down limit
8 up limit
9 emergency electric
running
1 low speed down
forced speed changing
I/O input signal logic
setting
Current value: 1
Setting: 1
【parameters
instruction】
0: NO
1: NC
6.5.12 Parameters setting---logic setting of car control board
【main menu】
A system control
B fault record
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management
H system
information
【parameters setting
inquiry】
P0 master drive control
P1 speed and
deceleration distance
P2 motor parameters
P3 encoder parameters
P4 running
comfortability
P5 elevator protection
parameters
P6 communication
setting
P7 drive information
PE factory only
【H1 logic of the car
control board】
00 car logic setting 1
01 car logic setting 2
02 car logic setting 3
03 car logic setting 4
04 single logic setting
of the car
05 reserved
06 reserved
07 reserved
08 reserved
