INVT EC160 User Manual

User manual of EC160 elevator intelligent integrated machine Function parameters
107
Setting value 00 01 02 03 04 05 06 07 08 09 10 11 12 13 14 15
Displaying ! " # $ % & ' ( ) * + , - . /
Setting value 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
Displaying 0 1 2 3 4 5 6 7 8 9 : ; < = > ?
Setting value 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47
Displaying @ A B C D E F G H I J K L M N O
Setting value 48 49 50 51 52 53 54 55 56 57 58 59 60 61 62 63
Displaying P Q R S T U V W X Y Z [ \ ] ^ _
Setting value 64 65 66 67 68 69 70 71 72 73 74 75 76 77 78 79
Displaying ` a b c d e f g h i j k l m n o
Setting value 80 81 82 83 84 85 86 87 88 89 90
Floor displaying
Corresponding table
Displaying p q r s t u v w x y z
6.5.11 Parameters setting---logic setting of I/O control board
【main menu】
A system control
B fault record
C language
selection
D parameters
setting inquiry
E password setting
F system
autotuning
G data
management
H system
information
【parameters setting
inquiry】
P0 master drive control
P1 speed and
deceleration distance
P2 motor parameters
P3 encoder parameters
P4 running comfortability
P5 elevator protection
parameters
P6 communication setting
P7 drive information
PE factory only
A1 floor setting
A2 floor displaying
H0 logic of the IO control
board
H1 logic of the car control
board
H2 front door stopping
floor
【H0 logic of the IO
control board】
00 logic setting 1
01 logic setting 2
02 logic setting 3
03 logic setting 4
04 logic setting 5
05 logic setting 6
06 I/O control board
logic setting
07 reserved
08 reserved
