User manual of EC160 elevator intelligent integrated machine Debugging at fast speed
155
(2) The elevator runs up to the up terminal forced deceleration switch acts, then the sill of the car is
below the sill of he hall about X (refer to 4.5.2).
(3) The elevator runs down to the down terminal forced deceleration switch acts, then the sill of the
car is above the sill of he hall about X (refer to 4.5.2).
(4) After the adjustment, restore the original connection.
6. Check the installation position and quantity of each leveling plate.
8.3 Parameter check
Check the controller parameters one by one according to the actual technical parameters. If there
is non-stopping floor on site and the non-sopping floor has no magnet vane, please set the total
floor as the actual stopping floor.
8.4 Autotuning of the hoistway position
1. Adjust the autotuning speed of the elevator (100mm/s by default, lower autotuning speed
contributes to fast leveling accuracy) and the elevator is in the state of engine room inspection
state.
2. Before autotuning, stop the elevator in the door area at the bottom floor. At the time, the
single down terminal deceleration switch needs to act and confirm the corresponding signal
on the main board.
3. Keep the safety circuit smooth.
4. Ensure the safety running of the elevator in the hoistway.
5. Begin the autotuning through the manual controller.
(1) Enter into the system autotuning menu and select the hoistway autotuning.
【main menu】
A
system control
B fault record
C language selection
D parameters setting
inquiry
E password setting
F system autotuning
G data management H
system information
【system autotuning】
[1] hoistway information
autotuning
[2] motor rotating
autotuning
[3] motor static
autotuning
[4] LL weighing
autotuning
[5] FL weighing
autotuning
[6] OL weighing
autotuning
【hoistway information
autotuning】
Please confirm the
position of the forced
speed changing
switch?
[Y] [N]
【forced speed
changing distance
instruction】
1
st
level: 1200mm
2
nd
level: 2400mm
