INVT EC160 User Manual

User manual of EC160 elevator intelligent integrated machine Function parameters
125
floor
H4 front/ rear door
stopping floor
L0 parallel and group
control setting
T0 time setting
F0 function setting
U0 calling signal
U1 system monitoring
U2 hoistway
information
16 test mode
17 relative selection of
CAN communication
18 relative selection of
elevator running
19 1387 encoder C/D
sampling
20 filter coefficient of stop
curve
21 peristaltic landing
distance
22 UPS application
57 front door IC open floor1
58 front door IC open floor2
……
98 reserved
Function
code
Instruction Setting range【default value】 Remarks
F0_00 High/low voltage detection 0~2【2】
Not modify in
running
Select for the safety circuit, hall lock and car lock circuit.
0: only detect high voltage, detect the BJ4 terminal
1: only detect low voltage, detect the 1KSAF and 1KDL in AJ2
2: detect high/low voltage
Function
code
Instruction Setting range【default value】 Remarks
F0_01 Hand door enabling 0~1【0】
Not modify
in running
0: invalid
1: arrival without open/closed detection. The elevator continues to run after switch off the door
lock.
