User manual of EC160 elevator intelligent integrated machine Function parameters
118
comfortability
P5 elevator protection
parameters
P6 communication
setting
P7 drive information
PE factory only
A1 floor setting
A2 floor displaying
H0 logic of the IO
control board
H1 logic of the car
control board
H2 front door stopping
floor
H3 rear door stopping
floor
H4 front/ rear door
stopping floor
L0 parallel and group
control setting
Function
code
Instruction Setting range【default value】 Remarks
L0_00 Group number of the elevator 0~10【0】
Not modify
in running
L0_01 Up bias floor 0~64【0】
L0_02 Down bias floor 0~64【0】
L0_03 Parallel home floor 0~64【0】
Set the parallel or group control parameters.
L0_00:
0: single elevator 1: parallel main elevator 2: parallel sub elevator 3 and above: group control
L0_01, L0_02 and L0_03 are needed in the parallel applications.
When there is only up bias for parallel elevators, set the up bias to main
