User manual of EC160 elevator intelligent integrated machine Function parameters
135
After enabling the communication IC card (in F0_18, bit3=1), open up 1~64 floor of front door by
F0_57~F0_60. The set floor will record internal command without using IC card.
For example, in a shopping mall, parking is under the 1st floor, home landing on the 1st floor,
stores on 2~5 floors, restaurants on the 12th floor, and other floors are private. The intelligent
control solution by using communication IC card is as follows:
When F0_18=8, the communication IC card is enabled. The home landing is fixed open floor in
no need of setting; set F0_57 to 1+4+8+16+32+4096=4157 to open up floors of the underground
parking, stores and restaurants.
【F0_57 front door 1-8
floor】
Valid IC Set value
【F0_57 front door 9-16
floor】
Valid IC Set value
1 floor 0 1 9 floor 0 256
2 floor 0 2 10 floor 0 512
3 floor 0 4 11 floor 0 1024
4 floor 0 8 12 floor 0 2048
5 floor 0 16 13 floor 0 4096
6 floor 0 32 14 floor 0 8192
7 floor 0 64 15 floor 0 16384
8 floor 0 128 16 floor 0 32768
Function
code
Instruction Setting range【default value】 Remarks
F0_61 Rear door 1~16 IC open floor 0~65535【0】
Not modify
in running
F0_62 Rear door 17~32 IC open floor 0~65535【0】
F0_63 Rear door 33~48 IC open floor 0~65535【0】
F0_64 Rear door 49~64 IC open floor 0~65535【0】
After enabling the communication IC card (in F0_18, bit3=1), open up 1~64 floor of rear door by
F0_61~F0_64. The set floor will record internal command without using IC card. 1 indicates open
up and 0 indicates IC card is valid. The setting is the same as above setting of front door floors.
Function
code
Instruction Setting range【default value】 Remarks
F0_70 Y5 relay output definition 0~65535【0】
Not modify
in running
F0_71 Y6 relay output definition 0~65535【0】
