INVT EC160 User Manual

User manual of EC160 elevator intelligent integrated machine Installation and wiring
28
Plug-in
No.
Pin
No.
Terminal definition Code
LED
indicator
code
Remarks
S8
Contact detection of
star-delta contactor
LINE3
LED11
Default NO input
S9
Inspection signal (off is
inspection)
INS1
LED12
Default NC input
S10
Inspection
UP button signal
UPB
LED13
Default NO input
S11
Inspection
DOWN button signal
DNB
LED14
Default NO input
S12 Up limit switch SUL LED15 Default NC input
S13 Down limit switch SDL LED16 Default NC input
S14
Low speed up forced
deceleration switch
SUS1
LED17
Default NC input
S15
Low speed down
forced deceleration
switch
SDS1
LED18
Default NC input
S16
Medium speed up
forced deceleration
switch
SUS2
LED19
Default NC input
CN4
terminals
1-10
S17
Medium speed down
forced deceleration
switch
SDS2
LED20
Default NC input
S18
Motor thermal
protection
SMTR
LED21
Default NO input
S19
Intelligent integrated
machine enabling
EN
LED22
Default NO input
S20 UPS detection KPWR
LED23 Default NO input
(disabled)
S21 Pre-opening feedback POF LED24 Default NO input
S22
Spare input 1
MF input terminal
LINE1 LED25 Default NO input
S23 Fire action input SFR LED26 Default NO input
