User manual of EC160 elevator intelligent integrated machine Function parameters
90
coefficient
22 Rated load
23 Weighing input selection
24 Weighing compensation
input channel
25 Pre-torque bias
26 Bias and gain at the
braking side
27 Bias and gain at the
drive side
28 Analog input filter of car
weighing
29 Analog input filter of
engine room
30 Smooth filter time of the
curve
Function
code
Instruction Setting range【default value】 Remarks
P4_00 ASR low speed proportional gain 0~100【20】
Not modify
in running
P4_01 ASR low speed integral time 0.01~10.00s【0.50】
P4_02
Speed detection low speed filter
times
0~8【0】
P4_03 Switch low point frequency 0.00Hz~10.00Hz【2.00】
P4_04
ASR high speed proportional
gain
0~100【20】
P4_05 ASR high speed integral time 0.01~10.00s【0.60】
P4_06
Speed detection high speed filter
times
0~8【0】
P4_07 Switch high point frequency 0~400【5.00】
The above parameters are only valid for vector control. When under the low point switch
frequency (P4_03), speed loop parameter PI is P4_00 and P4_01, when over the high low point
switch frequency (P4_07), speed loop parameter PI is P4_04 and P4_05. Please refer to
following figure for details.
