Goodrive270 series VFD for fan and pump Function parameter list
-169-
Function
code
Name Description Default
Modify
Bit 3: Output terminal state
Bit 4: PID reference value (% on)
Bit 5: PID feedback value (% on)
Bit 6: Set torque (% on)
Bit 7: AI1 (V on)
Bit 8: AI2 (V on)
Bit 9: AI3 (V on)
BIT10: High
-speed pulse HDIA frequency
BIT11: Reserved
Bi
t 12: Pulse count value
Bit 13: PLC and current step number of
multi
-step speed
Bit 14: Upper limit frequency (HZ on)
Bit 15: AI0 (V on)
P07.08
Frequency display
coefficient
0.01
±10.00
Display frequency = Running frequency * P07.08
1.00 ƻ
P07.09
Rotational speed
display coefficient
0.1
±999.9%
Mechanical rotation speed = 120 * (Displayed
running frequency) * P07.09/(Motor pole pairs)
100.0% ƻ
P07.10
Linear speed display
coefficient
0.1
±999.9%
Linear speed=(Mechanical rotation speed) *
P07.10
1.0% ƻ
P07.11
Rectifier bridge
temperature
-
20.0±120.0°C ƽ
P07.12
Inverter temperature
-20.0±120.0°C
ƽ
P07.13
Control board
software version
1.00
±655.35 ƽ
P07.14
Local accumulative
running time
0
±65535h ƽ
P07.15
VFD electricity
consumption MSB
Used to display
VFD electricity consumption.
VFD electricity c
onsumption = P07.15*1000 +
P07.16
P07.15
setting range: 0±65535 kWh (*1000)
P07.16 setting range: 0.0±999.9 kWh
ƽ
P07.16
VFD electricity
consumption LSB
ƽ
P07.17
Reserved
P07.18 VFD rated power
0.4
±3000.0kW
Model
depended
ƽ
