INVT GD270-090-4 - Page 35

Goodrive270 series VFD for fan and pump Installation guidelines
-25-
Figure 4±16 Pushing the VFD into the cabinet slowly
Note: Since the VFD barycenter is too high, use the auxiliary rope for mounting to prevent the VFD
from rollover during the push-in or push-out. See the following figure.
