Goodrive270 series VFD for fan and pump Basic operation guidelines
-50-
Function
code
Name Description Default
coefficient of
vector control
P03.09
Current-loop
proportional
coefficient P
0±65535 1000
P03.10
Current-loop
integral
coefficient I
0±65535 1000
P03.11
Torque setting
source
1: Keypad (P03.12)
2: AI1
3: AI2
4: AI3
5: Pulse frequency HDIA
6: Multi-step torque
7: Modbus communication
8: PROFIBUS/CANopen/DeviceNet communication
9: Ethernet communication
10: Reserved
11: EtherCAT/PROFINET communication
12: Programmable expansion card
13±17: Reserved
18: Keypad (for small power models)
Note: For setting sources 2±
6, 100% corresponds to
triple the motor rated current.
1
P03.12
Torque set
through keypad
-300.0%±300.0% (of the motor rated current) 50.0%
P03.13
Torque
reference filter
time
0.000±10.000s 0.010s
P03.14
Setting source
of forward
rotation
upper-limit
frequency in
torque control
0: Keypad (P03.16)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Multi-step setting
6: Modbus communication
7: PROFIBUS/CANopen/DeviceNet communication
0
