INVT GD270-090-4 - Page 61

Goodrive270 series VFD for fan and pump Basic operation guidelines
-51-
Function
code
Name Description Default
8: Ethernet communication
9: Reserved
10: EtherCAT/PROFINET communication
11: Programmable expansion card
12: Reserved
Note: For setting sources 1±5
, 100% corresponds to
the max. frequency.
P03.15
Setting source
of reverse
rotation
upper-limit
frequency in
torque control
0: Keypad (P03.17)
1±11: Same as those for P03.14
Note: For setting sources 1±5
, 100% corresponds to
the max. frequency.
0
P03.16
Forward rotation
upper-limit
frequency set
through keypad
in torque control
Setting range: 0.00 Hz±P00.03 (Max. output frequency)
50.00Hz
P03.17
Reverse rotation
upper-limit
frequency set
through keypad
in torque control
50.00Hz
P03.18
Setting source
of electromotive
torque upper
limit
0: Keypad (P03.20)
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDIA
5: Modbus communication
6: PROFIBUS/CANopen/DeviceNet communication
7: Ethernet communication
8: Reserved
9: EtherCAT/PROFINET communication
10: Programmable expansion card
11±17: Reserved
18: Keypad (for small power models)
Note: For setting sources 1±
4, 100% corresponds to
triple the motor rated current.
0
