Goodrive200A inverters Function parameters
44
Function
code
Name Detailed instruction of parameters
Default
value
Modify
three times of the rated current of the motor.
P03.12
Keypad
setting torque
Setting range: -300.0%~300.0%(rated current of
the motor)
50.0%
P03.13
Torque
reference
filter time
0.000~10.000s 0.010s
P03.14
Upper
frequency of
forward
rotation in
vector control
0:Keypad
(P03.16 sets P03.14,P03.17 sets P03.15)
1: AI1 (The inverter(15kW) can be set by the
analog potentiometer on the keypad and AI1
setting is not available for the device which is
18.5kW or higer than 18.5kW)
2: AI2
3: AI3
4:Pulse frequency HDI setting upper-limit
frequency
5:Multi-step setting upper-limit frequency
6:MODBUS communication setting upper-limit
frequency
7~ 9: Reserved
Note: Setting method 1~9, 100% corresponds to
the maximum frequency
0
P03.15
Upper
frequency of
reverse
rotation in
vector control
0
P03.16
Keypad
setting for
upper
frequency of
forward
rotation
This function is used to set the upper limit of the
frequency. P03.16 sets the value of P03.14;
P03.17 sets the value of P03.15.
Setting range:0.00 Hz~P00.03 (the Max. output
frequency)
50.00 Hz
P03.
17
Keypad
setting for
upper
frequency of
reverse
rotation
50.00Hz
P03.18
Upper electro
motion
torque
source
This function code is used to select the electro
motion and braking torque upper-limit setting
source selection.
0:Keypad setting upper-limit frequency
(P03.20 sets P03.18, P03.21 sets P03.19)
1: AI1 (The inverter(15kW) can be set by the
0
P03.19
Upper
braking
0
