Goodrive200A inverters Function parameters
55
Function
code
Name Detailed instruction of parameters
Default
value
Modify
P05.26
S7
terminal
switching-on
delay time
0.000s
○
P05.27
S7
terminal
switching-off
delay time
0.000s
○
P05.28
S8
terminal
switching-on
delay time
0.000s
○
P05.29
S8
terminal
switching-off
delay time
0.000s
○
P05.30
HDI
terminal
switching-on
delay time
0.000s
○
P05.31
HDI
terminal
switching-off
delay time
0.000s
○
P05.32
L
ower limit of
AI1
The inverter(≤15kW) can be set by the analog
potentiometer on the keypad and AI1 setting is
not available for the device which is 18.5kW or
higer than 18.5 kW.
The function code defines the relationship
between the analog input voltage and its
corresponding set value. If the analog input
voltage beyond the set minimum or maximum
input value, the inverter will count at the minimum
or maximum one.
When the analog input is the current input, the
corresponding voltage of 0~20mA is 0~10V.
In different cases, the corresponding rated value
of 100.0% is different. See the application for
detailed information.
The figure below illustrates different applications:
0.00V
○
P05.33
Correspondin
g setting of
the lower
limit of AI1
0.0% ○
P05.34
Upper limit of
AI1
10.00V
○
P05.35
Correspondin
g setting of
the upper
limit of AI1
100.0%
○
P05.36
AI1 input
filter time
0.100s
○
P05.37
L
ower limit of
AI2
0.00V
○
