Goodrive200A inverters Function parameters
63
Function
code
Name Detailed instruction of parameters
Default
value
Modify
BIT11:output terminals state
BIT12:torque set value(% on)
BIT13:pulse counter value
BIT14:length value
BIT15:PLC and the current stage in multi-step
speed
P07.06
Parameters
state 2
0x0000~0xFFFF
BIT0: AI1 (V on) (The inverter(≤15kW) can be
set by the analog potentiometer on the keypad
and AI1 setting is not available for the device
which is 18.5kW or higer than 18.5 kW)
BIT1: AI2 (V on)
BIT2: AI3 (V on)
BIT3: HDI frequency
BIT4: motor overload percentage (% on)
BIT5: the inverter overload percentage (% on)
BIT6: ramp frequency given value(Hz on)
BIT7: linear speed
BIT8: AC inlet current (A on)
BIT9: upper limit frequency (Hz on)
0x0000
P07.07
The
parameter in
the stop state
0x0000~0xFFFF
BIT0:set frequency
(Hz on, frequency flickering slowly)
BIT1:bus voltage (V on)
BIT2:input terminals state
BIT3:output terminals state
BIT4:PID reference (% flickering)
BIT5:PID feedback value(% flickering)
BIT6:reserved
BIT7:analog AI1 value(V on) (The inverter(≤
15kW) can be set by the analog potentiometer on
the keypad and AI1 setting is not available for the
device which is 18.5kW or higer than 18.5 kW)
BIT8:analog AI2 value(V on)
BIT9: analog AI3 value(V on)
BIT10:high speed pulse HDI frequency
BIT11:PLC and the current step in multi-step
speed
BIT12:pulse counters
BIT13:length value
BIT14: upper limit frequency (Hz on)
0x00FF
○
