Goodrive200A inverters Function parameters
74
Function
code
Name Detailed instruction of parameters
Default
value
Modify
2:Only digital potentiometer adjustments is valid
3:Neither ∧/∨ keys nor digital potentiometer
adjustments are valid
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1:Valid for all frequency setting manner
2:Invalid for multi-step speed when multi-step
speed has the priority
LED hundreds: action selection during stopping
0:Setting is valid
1:Valid during running, cleared after stopping
2:Valid during running, cleared after receiving the
stop command
LED thousands: ∧/∨ keys and digital
potentiometer integral function
0:The integral function is valid
1:The integral function is invalid
P08.43
Integral ratio
of the keypad
potentiomete
r
0.01~10.00s 0.10s ○
P08.44
UP/DOWN
terminals
control
0x00~0x221
LED ones: frequency control selection
0:UP/DOWN terminals setting valid
1:UP/DOWN terminals setting valid
LED tens: frequency control selection
0:Only valid when P00.06=0 or P00.07=0
1:All frequency means are valid
2:When the multi-step are priority, it is invalid to
the multi-step
LED hundreds: action selection when stop
0:Setting valid
1: Valid in the running, clear after stop
2: Valid in the running, clear after receiving the
stop commands
0x000
○
P08.45
UP
terminals
frequency
increasing
integral
ratio
0.01~50.00Hz/s
0.50
Hz/s
○
P08.46
DOWN
terminals
0.01~50.00 Hz/s
0.50
Hz/s
○
