INVT Goodrive 200A User Manual

Goodrive200A inverters Function parameters
87
Function
code
Name Detailed instruction of parameters
Default
value
Modify
P13.13
Braking
current of
short-circuit
When P01.00=0 during the starting of the
inverter, set P13.14 to a non-zero value to enter
the short circuit braking.
When the running frequency is lower than P01.09
during the stopping of the inverter, set 13.15 to a
non-zero value to enter into stopping short
circuited braking and then carry out the DC
braking at the time set by P01.12 (refer to the
instruction of P01.09~P01.12) .
Setting range of P13.13: 0.0~150.0%
(the inverter)
Setting range of P13.14: 0.00~50.00s
Setting range of P13.15: 0.00~50.00s
0.0%
○
P13.14
Braking
retention time
before
starting
0.00s
○
P13.15
The braking
retention time
when
stopping
0.00s
○
P14 Group Serial communication
P14.00
Local
communicati
on address
The setting range:1~247
When the master is writing the frame, the
communication address of the slave is set to 0;
the broadcast address is the communication
address. All slaves on the MODBUS fieldbus can
receive the frame, but the salve doesn’t answer.
The communication address of the drive is
unique in the communication net. This is the
fundamental for the point to point communication
between the upper monitor and the drive.
Note: The address of the slave cannot set to 0.
1 ○
P14.01
Communicati
on
baud ratio
Set the digital transmission speed between the
upper monitor and the inverter.
0:1200BPS
1:2400BPS
2:4800BPS
3:9600BPS
4:19200BPS
5:38400BPS
6:57600BPS
7:115200BPS
Note: The baud rate between the upper monitor
and the inverter must be the same. Otherwise,
the communication is not applied. The bigger the
baud rate, the quicker the communication
speed.
4 ○
P14.02
Digital bit
checkout
The data format between the upper monitor and
the inverter must be the same. Otherwise, the
1 ○
