INVT Goodrive 200A User Manual

Goodrive200A inverters Function parameters
86
Function
code
Name Detailed instruction of parameters
Default
value
Modify
pre-alarm and the inverter stops running after
overload fault
2: The inverter continues to work after overload
pre-alarm and the inverter stops running after
underload fault
3. The inverter stops when overloading or
underloading.
LED hundreds :
0:Detection all the time
1:Detection in constant running
Setting range of P11.09: P11.11~200%
Setting range of P11.10: 0.1~3600.0s
P11.11
Detection
level of the
underload
pre-alarm
If the inverter current or the output current is
lower than P11.11, and its lasting time is beyond
P11.12, the inverter will output underload
pre-alarm.
Setting range of P11.11: 0~P11.09
Setting range of P11.12: 0.1~3600.0s
50% ○
P11.12
Detection
time of the
underload
pre-alarm
1.0s ○
P11.13
Output
terminal
action
during
fault
Select the action of fault output terminals on
undervoltage and fault reset.
0x00~0x11
LED ones:
0:Action under fault undervoltage
1:No action under fault undervoltage
LED tens:
0:Action during the automatic reset
1:No action during the automatic reset
0x00 ○
P11.16
Extension
functions
selection
0x00~0x11
LED ones:Voltage drop frequency-decreasing
selection
0: Voltage drop frequency-decreasing selection
disable
1: Voltage drop frequency-decreasing selection
enable
LED tens: Step 2 ACC/DEC time option
0: Step 2 ACC/DEC time option disable
1: Step 2 ACC/DEC time option enable，when
running frequency more than P08.36, ACC/DEC
time switch to step 2 ACC/DEC time
00 ○
P13 Group Reserved
