INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Product overview
-7-
2.2 Product specifications
Function
Specification
Power input
Input voltage (V)
1PH 220(-15%)–240(+10%)
3PH 220(-15%)–240(+10%)
3PH 380(-15%)–440(+10%)
Input current (A)
Refer to section 2.5 "Rated specifications"
Input frequency (Hz)
50Hz or 60Hz, allowed range: 47–63Hz
Power
output
Output voltage (V)
Equal to input voltage (error < 5%)
Output current (A)
Refer to section 2.5 "Rated specifications"
Output power (kW)
Refer to section 2.5 "Rated specifications"
Output frequency
(Hz)
50Hz/60Hz, fluctuation:±5%
Technical
control
performance
Control mode
SVPWM
Max. output
frequency
400Hz
Adjustable-speed
ratio
1:100
Overload capability
150% of rated current: 1 minute
180% of rated current: 10 seconds
200% of rated current: 1 second
Key functions
Stop mode and anti-overtemperature of the bus
Temperature
measurement
accuracy
Overtemperature point ±3°C
Terminal analog input
resolution
≤ 20mV
Terminal digital input
resolution
≤ 2ms
Peripheral
interference
Analog input
1 input 0–10V/0–20mA
Analog output
1 input 0–10V/0–20mA
Digital input
5 common input
Digital output
1 Y output (commonly used with digital output)
and 1 pogrammable relay output
Communication
RS485 communication
Running
control
performance
Frequency setting
mode
Digital setting, analog setting, multi-step speed
setting, PID setting, Modbus communication
setting and so on.
Realizes switchover between the set
