INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Function parameters
-36-
Function
code
Name
Description
Default
Modify
P01.24
Delay of
the
stopping
speed
Setting range: 0.0–100.0 s
0.0s
○
P02 group Motor parameters
Function
code
Name
Description
Default
Modify
P02.01
Rated power
of AM
0.1–3000.0kW
Parameters of the controlled
asynchronous motor.
To ensure the control
performance, set
P02.01–P02.05 correctly
according to the information on
the nameplate of the
asynchronous motor.
You need to configure a motor
based on the standard motor
configuration of the VFD. If the
power of the motor is greatly
different from that of the
standard motor configuration,
the control performance of the
VFD degrades significantly.
Depend
on
model
◎
P02.02
Rated
frequency of
AM
0.01Hz–P00.03
(max. output
frequency)
50.00H
z
◎
P02.03
Rated speed
of AM
1–36000rpm
Depend
on
model
◎
P02.04
Rated
voltage of
AM
0–1200V
Depend
on
model
◎
P02.05
Rated
current of
AM
0.8–6000.0A
Depend
on
model
◎
P02.06
Stator
resistor of
AM
0.001–65.535Ω
These parameters are the
reference parameters for VFD
control, directly affecting the
control performance.
Note: Do not modify these
parameters unless it is
necessary.
Depend
on
model
○
P02.07
Rotor
resistor of
AM
0.001–65.535Ω
Depend
on
model
○
P02.08
Leakage
inductance
of AM
0.1–6553.5mH
Depend
on
model
○
