INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Optional peripheral accessories
-115-
VFD model
Input filter
GD10-0R4G-2-B
FLT-P04008L-C-G
GD10-0R7G-2-B
FLT-P04008L-C-G
GD10-1R5G-2-B
FLT-P04006L-C-G
GD10-2R2G-2-B
FLT-P04006L-C-G
GD10-0R7G-4-B
FLT-P04006L-C-G
GD10-1R5G-4-B
FLT-P04006L-C-G
GD10-2R2G-4-B
FLT-P04006L-C-G
Note:
 The input EMI meets the C3 requirements after an input filter is configured.
 The preceding table describes external accessories. You need to specify the ones you
choose when purchasing accessories.
C.6.3 C2 Filter model description
04
-
CA D E
FLT
L
B
P
016
F
B
-
Field
identifier
Field description
A
FLT: Name of the VFD filter series
B
Filter type
P: Power input filter
L: Output filter
C
Voltage class
S2: AC 1PH 220V (-15%)–240V (+10%)
04: AC 3PH 380V (-15%)–440V (+10%)
D
3-digit code indicating the rated current. For example, 016 indicates
16A.
E
Filter performance
L: General
H: High-performance
F
Filter application environment
A: Environment Category I (IEC61800-3), C1 (EN 61800-3)
B: Environment Category I (IEC61800-3), C2 (EN 61800-3)
