INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Optional peripheral accessories
-116-
C.6.4 C2 filter model selection
VFD model
Input filter
Output filter
GD10-0R2G-S2-B
FLT-PS2010H-A
FLT-L02010H-A
GD10-0R4G-S2-B
FLT-PS2010H-A
FLT-L02010H-A
GD10-0R7G-S2-B
FLT-PS2010H-A
FLT-L02010H-A
GD10-1R5G-S2-B
FLT-P04016L-B
FLT-L04016L-B
GD10-2R2G-S2-B
FLT-P04032L-B
FLT-L04032L-B
GD10-0R2G-2-B
FLT-P04006L-B
FLT-L04006L-B
GD10-0R4G-2-B
FLT-P04006L-B
FLT-L04006L-B
GD10-0R7G-2-B
FLT-P04006L-B
FLT-L04006L-B
GD10-1R5G-2-B
FLT-P04016L-B
FLT-L04016L-B
GD10-2R2G-2-B
FLT-P04016L-B
FLT-L04016L-B
GD10-0R7G-4-B
FLT-P04006L-B
FLT-L04006L-B
GD10-1R5G-4-B
FLT-P04006L-B
FLT-L04006L-B
GD10-2R2G-4-B
FLT-P04016L-B
FLT-L04016L-B
Note:
 The input EMI meets the C2 requirements after an input filter is configured.
 The preceding table describes external accessories. You need to specify the ones you
choose when purchasing accessories.
C.7 Braking system
C.7.1 Braking unit
The GD10 series VFDs do not provide braking units. If needed, you can select optional
braking units according to the lot number.
C.7.2 Braking resistor selection
When the VFD driving a high-inertia load decelerates or needs to decelerate abruptly, the
motor runs in the power generation state and transmits the load-carrying energy to the DC
circuit of the VFD, causing the bus voltage of the VFD to rise. If the bus voltage exceeds a
specific value, the VFD reports an overvoltage fault. To prevent this from happening, you
need to configure brake components.
 The design, installation, commissioning, and operation of the device
must be performed by trained and qualified professionals.
 Follow all the "Warning" instructions during the operation. Otherwise,
major physical injuries or property loss may be caused.
