INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Optional peripheral accessories
-117-
 Only qualified electricians are allowed to perform the wiring. Otherwise,
damage to the VFD or brake components may be caused.
 Read the braking resistor instructions carefully before connecting them
to the VFD.
 Connect braking resistors only to the terminals PB and (+). Do not
connect them to other terminals. Otherwise, damage to the brake circuit
and VFD and fire may be caused.
 Connect the brake components to the VFD according to the wiring
diagram. If the wiring is not properly performed, damage to the VFD or
other devices may be caused.
VFD model
Resistance
applicable for
100% brakign
torque
(Ω)
Dissipated
power of
braking
resistor
(kW)
Dissipated
power of
braking
resistor
(kW)
Dissipated
power of
braking
resistor
(kW)
Min.
allowable
braking
resistance
(Ω)
10% braking
usage
50% braking
usage
80% braking
usage
GD10-0R2G-S2-B
722
0.03
0.15
0.24
42
GD10-0R4G-S2-B
361
0.06
0.30
0.48
42
GD10-0R7G-S2-B
192
0.11
0.56
0.90
42
GD10-1R5G-S2-B
96
0.23
1.1
1.8
30
GD10-2R2G-S2-B
65
0.33
1.7
2.6
21
GD10-0R2G-2-B
722
0.03
0.15
0.24
42
GD10-0R4G-2-B
361
0.06
0.30
0.48
42
GD10-0R7G-2-B
192
0.11
0.56
0.90
42
GD10-1R5G-2-B
96
0.23
1.1
1.8
30
GD10-2R2G-2-B
65
0.33
1.7
2.6
21
GD10-0R7G-4-B
653
0.11
0.6
0.9
100
GD10-1R5G-4-B
326
0.23
1.1
1.8
100
GD10-2R2G-4-B
222
0.33
1.7
2.6
54
Note:
 Select braking resistors according to the resistance and power data provided by our
company.
 The braking resistor may increase the braking torque of the VFD. The preceding table
describes the resistance and power for 100% braking torque, 10% braking usage, 50%
braking usage, and 80% braking usage. You can select the braking system based on the
actual operation conditions.
