INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Function parameters
-42-
Function
code
Name
Description
Default
Modify
27: Wobbling frequency reset (return to the
center frequency)
28: Counter reset
30: ACC/DEC disabled
31: Counter trigger
33: Clear frequency increase/decrease
setting temporarily
34: DC brake
36: Command switches to keypad
37: Command switches to the terminals
38: Command switches to communication
P05.10
Input
terminal
polarity
The function code is used to set the polarity of
input terminals.
When a bit is 0, the input terminal is positive.
When a bit is 1, the input terminal is negative.
BIT4
BIT3
BIT2
BIT1
BIT0
S5
S4
S3
S2
S1
Setting range:0x000–0x01F
0x000
○
P05.11
Digital filter
time
The function code is used to set the filter time
for S1–S5. In strong interference cases,
increase the value to avoid mal-operation.
0.000–1.000s
0.010s
○
P05.12
Virtual
terminals
setting
Enable the virtual terminal input function in
communication mode.
0:Virtual terminals is invalid
1: Modbus communication virtual terminals
are valid
Note: After a virtual terminal is enabled, the
state of the terminal can be changed only in
communication mode. The communication
address is 0x200A.
0
◎
P05.13
Terminal
control
running
mode
The function code is used to set the mode of
terminal control.
0: 2-wire control 1, the enabling consistent
with the direction. This mode is widely used.
The defined FWD/REV terminal command
determines the motor rotation direction.
0
◎
