INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Function parameters
-60-
Function
code
Name
Description
Default
Modify
depending on the voltage class.
Note: It is only applicable to VFD models that
are built in optional braking tubes.
Setting range: 200.0–2000.0V
voltage:
700.0V
P08.39
Cooling fan
running mode
0: Common running mode
1: The fan keeps running after being powered
on
0
○
P08.40
PWM
selection
0x0000–0x0021
LED ones: PWM mode selection
0: PWM mode 1, 3PH modulation and 2PH
modulation
1: PWM mode 2, 3PH modulation
LED tens: low-speed carrier frequency limit
0: low-speed carrier frequency limit mode 1;
when the carrier frequency exceeds 1k at low
speed, limit to 1k.
1: low-speed carrier frequency limit mode 2;
when the carrier frequency exceeds 2k at low
speed, limit to 2k.
2: No limt for the carrier frequency at low
speed
0x01
◎
P08.41
Overmodulati
on
0:Invalid
1:Valid
1
◎
P08.42
Keypad data
control
setting
0x000–0x1223
LED ones: Frequency enable selection
0: ∧/∨ keys adjustments are valid
1:Reserved
2: ∧/∨ keys adjustments are invalid
3: Reserved
LED tens: Frequency control selection
0: Only valid when P00.06=0 or P00.07=0
1: Valid for all frequency setting manner
2: Invalid for multi-step speed when multi-step
speed has the priority
LED hundreds: Action selection during
stopping
0: Setting is valid
0x0000
○
