INVT Goodrive10 Series User Manual

Goodrive10 Series Mini VFD Fault tracking
-77-
Subject
Item
Method
Criterion
Check whether there are stains
and dust attached.
Visual inspection
No exception
occurs.
Note:
Discoloration of
copper bars
does not mean
that they cannot
work properly.
Conductor
and wire
Check whether the conductors are
deformed or their color change
due to overheat.
Visual inspection
No exception
occurs.
Check whether the wire sheaths
are cracked or their color
changes.
Visual inspection
No exception
occurs.
Terminal
block
Check whether there is damage.
Visual inspection
No exception
occurs.
Filter
capacitor
Check whether there is electrolyte
leakage, discoloration, cracks,
and chassis expansion.
Visual inspection
No exception
occurs.
Check whether the safety valves
are released.
Determine the
service life
based on the
maintenance
information, or
measure them
through
electrostatic
capacity.
No exception
occurs.
Check whether the electrostatic
capacity is measured as required.
Use instruments
to measure the
capacity.
Electrostatic
capacity ≥ initial
value × 0.85
Resistor
Check whether there is
displacement caused due to
overheat.
Olfactory and
visual inspection
No exception
occurs.
Check whether the resistors are
disconnected.
Visual
inspection, or
remove one end
of the connection
cable and use a
Resistance
range: ±1 0% (of
the standard
resistance)
