INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-96-
Function
code
Name
Description
Default
value
Modify
P17.20
AI2 input
voltage
This function code displays the AI2 input signal.
Range: 0.00–10.00V
●
P17.21
AI3 input
voltage
This function code displays the AI3 input signal.
Range: -10.00–10.00V
●
P17.23
PID reference
value
This function code displays the PID reference
value.
Range: -100.0–100.0%
●
P17.24
PID feedback
value
This function code displays the PID feedback
value.
Range: -100.0–100.0%
●
P17.25
Motor power
factor
This function code displays the motor power
factor.
Range: -1.00–1.00
●
P17.26
Present running
time
This function code displays the present running
time of the VFD.
Range: 0–65535min
●
P17.27
Simple PLC and
present step of
multi-step speed
This function code displays the simple PLC and
present step of multi-step speed.
Range: 0–15
●
P17.28
ASR controller
output
This function code displays the ASR controller
output in vector control, relative to a percentage
of the motor rated torque.
Range: -300.0%–300.0% (of the motor rated
current)
●
P17.29–
P17.31
Reserved
●
P17.32
Magnetic flux
linkage
This function code displays the magnetic flux
linkage of the motor.
Range: 0.0%–200.0%
●
P17.33
Exciting current
reference
This function code displays the exciting current
reference in vector control.
Range: -3000.0–3000.0A
●
P17.34
Torque current
reference
This function code displays the torque current
reference in vector control.
Range: -3000.0–3000.0A
●
P17.35
AC input current
This function code displays the incoming line
current on the AC input side.
●
