INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-95-
Function
code
Name
Description
Default
value
Modify
power. A positive value indicates electrical
driving state, and a negative value indicates
electricity generation state.
Range: -300.0–300.0% (relative to the motor
rated power)
P17.09
Output torque
This function code displays the present output
torque of the VFD, for which 100.0% is relative to
the motor rated torque. A positive value indicates
electrical driving state, and a negative value
indicates electricity generation state.
Range: -250.0–250.0%
●
P17.10
Estimated motor
frequency
This function code displays the estimated motor
rotor frequency in open loop vector control.
Range: 0.00– P00.03
●
P17.11
DC bus voltage
This function code displays the present DC bus
voltage of the VFD.
Range: 0.0–2000.0V
●
P17.12
Digital input
terminal status
This function code displays the present digital
input terminal status of the VFD.
Range: 0000–00FF
●
P17.13
Digital output
terminal status
This function code displays the present digital
output terminal status of the VFD.
Range: 0000–000F
●
P17.14
Digital
adjustment
This function code displays the adjustment set
through the keypad.
Range: 0.00Hz–P00.03
●
P17.15
Torque
reference
This function code displays torque reference, the
percentage of the motor rated torque.
Range: -300.0%–300.0% (of the motor rated
current)
●
P17.16
Linear speed
This function code displays the present linear
speed of the VFD.
Range: 0–65535
●
P17.17
Reserved
●
P17.18
Counting value
This function code displays the present counting
value of the VFD.
Range: 0–65535
●
