INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-94-
Function
code
Name
Description
Default
value
Modify
When it is 1, if the dual system is running
properly, but #2 inverter unit (or #1 inverter unit)
encounters a fault, #1 inverter unit (or #2 inverter
unit) coasts to stop and displays the fault code of
#2 inverter unit (or #1 inverter unit).
P14.16
Reserved
P14.17
LIN
communication
fault timeout
time
0.0 (invalid), 0.1–60.0s
0.0s
○
P17 Status viewing
P17.00
Set frequency
This function code displays the set frequency of
the VFD.
Range: 0.00Hz–P00.03
●
P17.01
Output
frequency
This function code displays the present output
frequency of the VFD.
Range: 0.00Hz–P00.03
●
P17.02
Ramp reference
frequency
This function code displays the present ramp
reference frequency of the VFD.
Range: 0.00Hz–P00.03
●
P17.03
Output voltage
This function code displays the present output
voltage of the VFD.
Range: 0–1200V
●
P17.04
Output current
This function code displays the present output
current of the VFD.
Range: 0.0–5000.0A
●
P17.05
Motor rotation
speed
This function code displays the motor rotation
speed.
Range: 0–65535RPM
●
P17.06
Torque current
This function code displays the present torque
current of the VFD.
Range: 0.0–5000.0A
●
P17.07
Exciting current
This function code displays the present exciting
current of the VFD.
Range: 0.0–5000.0A
●
P17.08
Motor power
This function code displays the motor power, for
which 100.0% is relative to the motor rated
●
