INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Optional peripheral accessories
-150-
Field
Description
D
3-digit development serial number. For example, 003 stands for the serial
number of C3 filters in development.
E
Filter performance
L: General
H: High-performance
F
Filter application environment
A: Environment Category I (IEC61800-3:2004), C1 (EN 61800-3:2004)
B: Environment Category I (IEC61800-3:2004), C2 (EN 61800-3:2004)
C: Environment Category II (IEC61800-3:2004), C3 (EN 61800-3:2004)
G
Market management number
G: Special for external C3 filter
C.6.2 C3 filter model selection
Goodrive18 serires two-in-one VFD can meet IEC61800-3 C3 requirement only after
connecting to an external filter.
VFD model
Input filter
GD18-0R7-4-2
FLT-P04006L-B
GD18-1R5-4-2
FLT-P04016L-B
GD18-2R2-4-2
FLT-P04016L-B
GD18-004-4-2
FLT-P04032L-B
GD18-5R5-4-2
FLT-P04032L-B
GD18-7R5-4-2
FLT-P04045L-B
The preceding table lists external accessories. You need to specify the ones you choose when
purchasing accessories.
If you need C2 filters, consult INVT technical personnel for detailed configuration solutions.
