Note: By default, S1–S4 are assigned to #1
inverter unit, and S5–S8 are assigned to #2
inverter unit. If you want to change the
configuration, see section 5.2 for details.
0: No function
1: Forward rotation operation
2: Reverse rotation operation
3: 3-wire control operation
4: Forward jogging
5: Reverse jogging
6: Coast to stop
7: Fault reset
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Cancel the frequency change setting
13: Shift between A setting and B setting
14: Shift between combination setting and A
setting
15: Shift between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi-step speed terminal 4
20: Multi-step speed pause
21: ACC/DEC time selection terminal 1
22: ACC/DEC time selection terminal 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Traverse pause (stop at the current
frequency)
27: Traverse reset (return to the center
frequency)
28: Counter reset
