INVT Goodrive18 Series User Manual

Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-90-
Function
code
Name
Description
Default
value
Modify
P14.00
Local
communication
address
Setting range: 1–247
When the master is writing a frame, the
communication address of the slave is set to 0;
the broadcast address is the communication
address. All slaves on the Modbus fieldbus can
receive the frame, but the salves do not need to
answer.
The local communication address is unique in
the communication network. This is the
fundamental for the point to point communication
between the upper monitor and the VFD.
Note: The address of a slave cannot be set to 0.
To prevent conflict, P14.00 is 1 by default, while
F14.00 is 2 by default.
1
○
P14.01
Communication
baud rate
This function code is used to set the data
transmission rate between the upper monitor
and the VFD.
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
6: 57600BPS
Note: The baud rate between the upper monitor
and the VFD must be the same. Otherwise, the
communication fails. A greater baud rate
indicates a higher communication speed.
4
○
P14.02
Data bit check
setting
0: No check (N, 8, 1) for RTU
1: Even check (E, 8, 1) for RTU
2: Odd check (O, 8, 1) for RTU
3: No check (N, 8, 2) for RTU
4: Even check (E, 8, 2) for RTU
5: Odd check (O, 8, 2) for RTU
6: No check (N, 7, 1) for ASCII
7: Even check (E, 7, 1) for ASCII
8: Odd check (O, 7, 1) for ASCII
1
○

INVT Goodrive18 Series Specifications

General

Cooling Method	Forced air cooling
Output Voltage	3-phase 0~Input Voltage
Output Frequency	0~600Hz
Control Mode	Sensorless Vector Control (SVC), Voltage/Frequency (V/F) control
Braking Unit	Built-in or external (optional)
Communication Protocol	Modbus RTU
Protection Features	Overcurrent, overvoltage, undervoltage, overheat, overload, short circuit, phase loss
Enclosure Rating	IP20
Ambient Temperature	-10°C to +40°C
Storage Temperature	-20°C to +60°C
Humidity	≤95% RH, non-condensing
Altitude	Up to 1000m (derating above 1000m)
Dimensions	Varies depending on power rating. Consult product manual for specific dimensions.
