Page #97 background imageLoading...
Page #97 background image
Goodrive18 series two-in-one VFD Function parameters and function terminal reuse
-92-
Function
code
Name
Description
Default
value
Modify
P14.06
Communication
processing
action selection
0x0000x111
LED ones: Responding to write operations
0: Yes
1: No
LED tens: Communication encryption
0: Disable
1: Enable
LED hundreds: User-defined communication
command address
0: Invalid
1: Valid
0x000
P14.07
User-defined
address for
running
commands
0x00000xffff
0x1000
P14.08
User-defined
address for
frequency
setting
0x00000xffff
0x2000
P14.10
Keypad
selection
0: The keypad display #1 inverter unit
information (group P)
1: The keypad display #2 inverter unit
information (group F)
Note: F14.10 is set to 1 by default.
0
P14.11
Digital input
interaction
control
0: Invalid
1: Valid
When it is invalid, #1 inverter unit cannot use
input of S5S8, and #2 inverter unit cannot use
input of S1S4.
When it is valid, interaction control is
implemented for the input terminals for which
P05.01P05.08 are 0.
For example, if F05.05 is 0 (#2 inverter unit does
not occupy S5), #1 inverter unit can use the input
of S5. Similarly, if F05.01 is 0 (#1 inverter unit
does not occupy S1), #2 inverter unit can use the
input of S1.
0
