A. Left End Cover

B. Safety Cover

C. Right End Cover

D. Take-up Motor

E. Stand Leveling Foot

F. Feed Roll

G. Take-up Shaft

H. Feed Shaft

I. Stand

KEY

Figure 2. The Ioline FlexJet Printer Front View.
