iPECS eMG80 - Specifications; General Specifications

iPECS eMG80
Hardware Description and Installation Manual Issue 1.3
9
2.5 Specifications
2.5.1 General Specifications
Table 2.5.1-1 General Specifications
Item
Description
Specification
CPU M83261G, ARM11 dual core (32bit, 650MHz)
RTC Back-up Battery
Duration
7 years
PSU
AC Voltage Input
100~240 +/- 10% Volt AC @ 47-63 Hz
AC Power consumption 90 Watts
AC Input Fuse
2A @250 Volt AC
DC Output Voltage +5, -5, +27, +30 Volt DC
External Backup Battery
Input Voltage
+24 Volt DC (+12 VDC x 2 each KSU)
Battery Fuse 5.0A @250 Volts AC, 5AG
Charging Current
Max. 200 mA
Battery Load Current Max. 3A (KSU only), Max. 6A (KSU+ EKSU)
Ring Signal
65 Vrms @ 25Hz
External Relay Contact
1A @30 Volt DC
Music Source Input
0 dBm @600 ohm
External Paging Port
0 dBm @600 ohm
Ring Detect Sensitivity
30 Vrms @16-55 Hz
DTMF Dialing
Frequency Deviation Less than +/-1.8%
Signal Rise Time 5 ms
Tone Duration, on time Min. 50 ms, Normal 100 ms
Inter-digit Time
Min. 30 ms, Normal 100 ms
Pulse Dialing
Pulse Rate 10 PPS
Break/Make Ratio
60/40% or 66/33%
Operating Environment
Temperature 0 (
o
C) - 40 (
o
C)
Humidity 0 - 80% (non-condensing)
Dimension
KSU 307 mm(W) x 294 mm(H) x126.6 mm(D)
Expansion KSU
307 mm(W) x 294 mm(H) x126.6 mm(D)
Weight
KSU 2.03 Kg
Expansion KSU
1.99 Kg
MODU
Analog Modem Bell, ITU-T, V.34 V.32BIS, V.90
Speed 300 bps up to 33K bps speed rate
Connection Automatic rate negotiation
VoIP
LAN Interface
10/100 Base-T Ethernet (IEEE 802.3)
Speed 10/100 Mbps (Auto-Negotiation)
Duplex
Half or Full Duplex (Auto-Negotiation)
VoIP Protocol SIP and H.323 Revision 2
Voice Compression G.711/G.726/G.729/G.723.1
Voice/Fax Switching T.38
Echo cancellation
G.165
