3.2 Installation Overview
The installation is conducted in 7 steps as indicated in the below list.
1. Pre-Install preparations, section 3.3
2. Install Interface and Function boards, section 4
3. Mount the KSU and EKSU, section 5
4. Wire the KSU and EKSU, section 6
5. Terminal Installation and Wiring, section 7
6. Power- up & run Wizard, section 8
7. DECT Installation, refer to the DECT manuals, GDC-600TBE (CRS tool) and GDC-
600BE Manual, available from the local Ericsson-LG Enterprise representative.
3.3 Preparation
In preparation for the installation, locate an appropriate site for the KSU installation
considering the precautions mentioned in earlier sections, wiring, access to power, etc. Also,
if installing DECT, locate the best estimated position for the Base Stations. The permanent
location of the Base Station will be determined using the GDC-600TBE CSR Tool to perform a
RF coverage survey.
Once the mounting site is identified, verify all equipment and wiring charts are available on-
site. Unpack the KSU and, if required, the EKSU and verify the contents include the items
shown in Figure 3.1 and 3.2.
Note the Expansion cable is provided only with the Expansion KSU.
