iPECS eMG80 - System Capacity

iPECS eMG80
Hardware Description and Installation Manual Issue 1.3
10
2.5.2 System Capacity
Three System Capacity charts are provided below. These include the General System
Maximum Capacities Table 2.5.2-1, the capacity based on the MBU type Table 2.5.2-2 to
Table 2.5.2-5. Note that the maximums are not simultaneously achievable. However, the
maximum number of VoIP channels is separate from other external network and station
maximums. That is, up to 16 VoIP channels are available in addition to CO, BRI and PRI
Lines. Also, the 48 DECT stations are separate from other station maximums.
Table 2.5.2-1 General System Capacities
Item Capacity
CO/Trunk lines Max. 74
Stations Max. 140
Attendants 4
LAN port 2 (1 each, KSU and VVMU)
Modem Channel 1 (MODU)
Serial Port(RS-232C)
1
USB(2.0) Host port 1
Alarm/Doorbell input 2 (1 per KSU)
External Control Relays 2 (1 per KSU)
Music Source Inputs
1 Internal: select one of 13 melodies
1 External source input
5 SLT ports
3 VSF announcements
Power Fail Circuit Max. 6 (1 per KSU, EKSU, CH204, CH408, CS416)
VSF Device 1: Built-in AA/VM
w/MEMU
w/MEMU2
VSF Device 2 (VVMU)
8 channels(2 Chan. by default, 1 Channel by license), 1 hour
15 hours(no license needed)
60 hours(no license needed)
8 channels (by license) & 15 hours(by license), 1 hour(by default)
Conference channels 148 channels/13 party per group
WTIB 1
DECT Phones 48
Built-in VoIP channels 8 (2 channels by default, 6 channels by license)
VVMU VoIP channels 8 (by license)
IP Stations and SIP Trunks
48 port (32 Stations+16 SIP Trunks)
External Page 1 port
Internal Page 35 zones
System Speed Dial 3000 numbers, 25 digits each
System Speed Dial Zones
(Groups)
10 zones
Station Speed Dial 100 per station, 25 digits each (Max. 4000 numbers)
