iPECS eMG80
Hardware Description and Installation Manual Issue 1.3
12
Table 2.5.2-2 KSUA Device Type Maximums
Resource
Type
Device Type Maximum Capacity Interface Boards
External
Network
KSUA: 4 CO & 1 DKT + 7 Hybrid & 2VoIP
CO Line
12
2 CH408 or 1 CH408 + 1 CS416
BRI Line 4 (2B+D) & 4 CO Line 2 BH208
PRI/E1 Line 0
SIP Trunks 16 channels
6-licensed + VVMU
Shared w/Local/Remote IP & SIP phones
EKSU
CO Line 12 2 CH408 or 1 CH408 + 1 CS416
KSUA + EKSU
CO Line 24
BRI Line 4 (2B+D) & 16 CO Lines
PRI Line 0
SIP Trunk
16 channels
Stations
KSUA
DKT 24 2 CH408 or BH208 or combination
SLT 31 & 1-DKT 1 (CH408 or BH208) + 1 CS416
LIP/SIP 32
6-licensed + VVMU
Shared w/SIP Trunks
16 simultaneous calls
DECT 48
WTIB4
24 simultaneous calls, 6/Base
EKSU
DKT 24 2 CH408
SLT 32 1 CH408 +1CS416
KSUA + EKSU
DKT
48
SLT 63 & 1-DKT
LIP/SIP 32 SIP Phones require per seat license
DECT 48
