Product Description
Modline 5
Rev. L6 Feb 2017 17
Series 56: Sensor Model Numbers
Emissivity span is limited to 0.3 to 1.0 for the first 55°C (100°F) for all temperature ranges
Model
Temperature Range in °C and (°F)
Optical Resolution with Type 6A Lens
56-0315
50 to 300°C (122 to 572°F)
D/150
56-0415
100 to 400°C (212 to 752°F)
D/150
56-0815
200 to 800°C (392 to 1472°F)
D/150
Series 5G: Sensor Model Numbers
Emissivity span is limited to 0.3 to 1.0 for the first 55°C (100°F) for all temperature ranges
Model
Temperature Range in °C and (°F)
Optical Resolution with Type 2A Lens
5G-1007
250 to 1000°C (482–1832°F)
D/75
5G-1415
300 to 1400°C (572–2552°F)
D/150
5G-2024
350 to 2000°C (662 – 3632°F)
D/240
Series 5R: Sensor Model Numbers
Model
Temperature Range in °C and (°F)
Optical Resolution with Type RA Lens
5R-1410
600 to 1400°C (1112 – 2552°F)
D/100
5R-1810
700 to 1800°C (1292 – 3272°F)
D/100
5R-3015
1000 to 3000°C (1832– 5432°F)
D/150
Through the Lens Sight – Required Selection
Visible or Optional Laser Sighting.
Lens Types
Lens selection requires matching the lens to specific models. Lens types ending in A are considered
standard focusing range lenses. Lens types ending in B are considered close focus lenses. Lens types
ending in C are considered very close focus lenses. Complete lens focusing ranges and spot size
information are found in Section 3 Sensor Installation, page 22 of this manual.
Dirty Window Detector Option – Required Selection
The selection is Installed or None. The product is covered by Patent Number 5812270 when the Dirty
Window Detector Option is installed.
2.4 Modline 5 Model Number Summary
Modline 5 Model Number as Found on Serial Number Label
