Sensor Installation
Modline 5
Rev. L6 Feb 2017 33
Presentation of accessories and sensor installation is organized in the Sections below as follows.
Sensor dimensions and specifications.
General requirements for all installations including cable clearances, access for aiming,
focusing and setup.
Description of each accessory accompanied by dimensions and specifications.
A table of recommended accessory groupings.
Illustrations of the groupings accompanied by overall dimensions.
Other accessories such as pipe mounts, sight tubes, target tubes window assemblies, etc. is referenced
at the end of this section.
3.7.2 Sensor Dimensions
The dimensions of the Standard and Dirty Window Detector Modline 5 Sensors are given below. These
dimensions are without any mounting accessories.
Figure 15: Standard Modline 5 Sensor
Figure 16: Dimensions Standard Sensor
Figure 17: Sensor with Dirty Window Detector (DWD)
