Product Description
Modline 5
Rev. L6 Feb 2017 19
2.5.2 Power and Interface Accessories
Model POI – Power Supply/Signal Interface Box.
This box includes a 24VDC power supply, interconnecting cable termination strip, and RF suppression
components. Input power is 100 to 240 VAC 50/ 60 HZ.
Model TSP – Terminal Strip Plate
This plate includes an interconnecting cable termination strip and RF suppression components.
Model DPM – Digital Panel Meter
Digital Temperature Indicator and RS-485 Communication Operator Interface. 85 to 250 VAC 50/ 60 Hz.
The DPM does not provide power to Sensor.
2.5.3 Installation Accessories
Details on the following standard accessories can be found in Section 3 Sensor Installation, page 22. An
extended family of accessories is available and they are referenced in Section 3.
Standard Modline 5 Accessories
Model – MFS Mounting Flange (Small Diameter Pattern)
Model – BMA Base Mount Adapter
Model – APA Air Purge Accessory
Model – WJA Water Jacket Accessory
Model – ESA Dirty Window Detector Extension Sleeve Adapter
(one included with Dirty Window Detector Option)
Model – UAA Universal Accessory Adapter
Model – MFL Mounting Flange Large
Model – RAM Right Angle Mount
Model – M5WJ5 Mounting Kit to mount Sensor in WJ-5 Water Cooling Jacket
Protective Window / Sight Accessory
The EP – 5 with a dimming filter is available for viewing very high temperatures. This window replaces
the standard rear protection / sight window supplied with the Sensor. This filtered window is for
viewing high temperature targets from 1200°C (2192°F) to 2300°C (4172°F).
Spare part standard protection windows are identified as the RPW, rear protection window assembly
with clear sight window. One of these is supplied with every Sensor.
