Product Description
Modline 5
Rev. L6 Feb 2017 21
targets or combinations of these conditions above target
temperatures of 1500°F (800°C).
System ALARM Relay Contacts 24 V AC/DC at 1 Amp. Resistive
Peak Picker Rise Time Same as selected Response Time
Peak Picker Decay Rate Adjustable 0.00 to 300 degrees F (0.00 to 166 degrees C)
per second
Peak Picker Reset: Internal Reset has two Modes: Manual and Auto.
External Reset: Contact closure greater than .08 second
Track and Hold Tracking Mode is elected with external contact closure
Power Requirements 24 VDC +/- 5%, 8 Watts Maximum
Operating Ambient Temperature
Sensor Series 52, 56, 5R and 5G: 0 to 55°C F (32 to 130°)
With WJA Accessory Air Cooling 0 to 105°C (32 to 220°F)
With WJA Accessory Water Cooling: 0 to 200°C (32 to 400°F)
Sensor Environmental
Sensor Housing NEMA 4 (IP65).
Sensor Cable Plug and
Housing Connector NEMA 4 (IP65).
Humidity 10 to 90% non-condensing
Sensor Dimensions See dimensional drawings in section 3.7.2 Sensor Dimensions,
page 33.
Weight 4 lbs. (1.8 kg) approximate, Model and option dependent
Laser Sight Option Laser: Class II Less than 1 mw at 635 nm
Shock IEC 68 - 2-27
Vibration IEC 68 -2-6
2.6.2 Accessory Specifications
POI Power Supply/Signal Interface Box
Ambient Temperature: 0 to 55°C (32 to 130°F)
Environmental: NEMA 4 (IP65)
Power Requirements: 100 to 240VAC 50/ 60 HZ, 40 VA.
DPM Digital Panel Meter
Ambient Temperature: 0 to 50°C (32 to 122°F)
Environmental: NEMA 4X (IP65) Sealed Front Bezel
Power Requirements: 85 to 250 VAC 50/60 HZ, 15VA.
Terminal Strip Plate
Ambient Temperature: 0 to 55°C (32 to 130°F)
