ircon Modline 5 - Page 45

Sensor Installation
Modline 5
Rev. L6 Feb 2017 43
Figure 29: MFS Accessory
Material: Clear Anodized Aluminum
Weight: Approximately 1 Pound (0.5 kilograms)
Table 5: MFS Mounting and Assembly Supplied Parts List
Figure 30: MFS Dimensions
Dimensions are in inches and (millimeters). Do not scale.
Qty
Part No.
Description and use
User Supplied Tools
3
230630C60
M6 X 30 mm flat head cap screws to assemble the MFS with the
APA air purge
5 mm hex key wrench
Countersink holes for APA Air Purge
3 Places M6 flat head screws
Front Side
Mounting Bolt Circle
Hole
APA Air Purge mounts to Back Side
