Sensor Installation
Modline 5
Rev. L6 Feb 2017 51
4. The ESA adds 1.82 in. (46.2 mm) to length of the assembled group.
5. Use water for cooling only. Do not use air for cooling with DWD unless the APA air purge accessory is used. See
information in Section 3.9.6 WJA – Water Jacket Accessory Description and Dimensions.
Table 7: 3.10.1 Recommended Accessory Groupings
