ISHIDA IGB-60 - Weighing Condition Setting Table

Manual No. 085-3435-07 22/45 IGB/IGX Series (Overseas Specifications) Service Manual
Weighing Condition Setting Table
Address Weight Item Data
110A 1 Decimal point position 0: 0 1: 0.0
2 2: 0.00 3: 0.000
4 Minimum graduation 0: 1 (1-2 change in Dual range/ Multi Interval)
4: 2 (2-5-10 change in Dual range/ Multi Interval)
8 8: 5 (5-10-20 change in Dual range/ Multi Interval)
C: Invalid
110B - Accuracy (Resolution) 0: 1/500 1: 1/600 2: 1/750 3: 1/1000
4: 1/1200 5: 1/1500 6: 1/2000 7: 1/2500
8: 1/3000 9: 1/4000 A: 1/5000 B: 1/6000
C: 1/7500 D: 1/10000 E: 1/12000 F: 1/15000
1
2
4
Changing method 0: Single range LED stable display only (IGX)
1: 1/3000 Multi interval Stabe/Upper/Lower display (IGB)
2: Single range Upper/Lower display (IGX)
3: 1/3000 Multi interval Stabe/Upper/Lower display (IGB)
4: Single range (Body weight specification)
5: 1/3000 Dual range (A/B range change)
6: Single range (lb/kg change)
7: 1/3000 Multi interval (lb/kg change)
111A
8
1
Weight unit
(Valid only for
communications)
<111A> <111B>
0 + 0: kg (kg - lb)
8 + 0: g
0 + 1: lb
8 + 1: oz
2
4
111B
8
Filter setting
Do not change the data.
(Cut off) (Notch) (Output rate)
0: 0.66Hz 2.50Hz 400ms
2: 0.84Hz 3.20Hz 312ms
4: 1.05Hz 4.00Hz 250ms
6: 1.31Hz 5.00Hz 200ms
8: 1.68Hz 6.40Hz 156ms
A: 2.10Hz 8.00Hz 125ms
C: 2.62Hz 10.00Hz 100ms
E: 3.35Hz 12.80Hz 78ms
