ISHIDA INS-100 - Reference Data; E2 ROM Map (0 - 127) Data Format

Chapter 4 REFERENCE DATA
32 INS-100 Service Manual No. 085-6692-09
4. REFERENCE DATA
4.1 E2ROM Map (0 – 127) Data Format
Address
Data Content Data Range
0 - 99 Preset data
100A Scale mode data 0 - 16
100B Reserve
101 100A and 100B check data (writing twice)
102A
ON/OFF key function selection (bit 0)
Invalid Preset automatic call function selection (bit 1)
Invalid 16/24 digit printer selection (bit 2)
Invalid Date print function selection (bit 3)
0 - 1 (F1)
0 - 1 (F2)
0 - 1 (F3)
0 - 1 (F4)
102B
Invalid Preset number print function selection (bit 4)
Invalid Single/Continual label print selection (bit 5)
Invalid Tare weight print function selection (bit 6)
Invalid Upper/Lower limit value print function selection
(bit 7)
0 - 1 (F5)
0 - 1 (F6)
0 - 1 (F7)
0 - 1 (F8)
103A Invalid Baud rate setting (bit 0 - 3) 0 - 16 (F9)
103B Invalid Output message specification (bit 4 - 7) 0 - 16 (F10)
104A Invalid Data output method (bit 0 - 3) 0 - 16 (F11)
104B Invalid Data output condition (bit 4 - 7) 0 - 16 (F12)
105A Invalid Contact output signal setting (bit 0 - 3) 0 - 16 (F13)
105B Invalid Contact input signal setting (bit 4 - 7) 0 - 16 (F14)
106A Invalid Large volume buzzer output setting (bit 0 - 3) 0 - 16 (F15)
106B Built-in buzzer selection function (bit 4 - 7) 0 - 16 (F16)
107A Automatic power OFF setting (bit 0 - 3) 0 - 6 (F17)
107B Reserve
108 - 109 102 – 107 checksum
110 - 115A
Weighing setting data (weight)
Note: Refer to the scale setting table.
115B, 116A, 116B
Weighing setting data (price calculation)
Note: Refer to the scale setting table.
117A
Country code
Note: Refer to the country code table.
0 - 15
117B Reserve
118 - 120 A/D zero point data (adrift) 24 bits
121 - 123 A/D calibration data (ad width) 24 bits
124
Weighing capacity setting (1, 60kg multi-range)
Note: Refer to the weighing capacity setting table.
0 - 99
125A
District code (1-16 districts)
Note: Refer to the district code table.
0 - 15
125B
Adjusted span flag
5H = OK Others = Error
5H or others
126, 127 No.100 - 113 checksum
Note: F2 – F15 is Invalid function.
